High-strength Carbon Steel Tubes For Heat Transfer Applications
Astm a214 erw boiler tubes offer high-strength, corrosion-resistant solutions for heat exchangers, condensers, and boiler systems.
High-strength Carbon Steel Tubes For Heat Transfer Applications
Astm a214 erw boiler tubes offer high-strength, corrosion-resistant solutions for heat exchangers, condensers, and boiler systems.
ASTM A214 ERW Boiler Tube is a minimum-wall-thickness, electric-resistance-welded (ERW) carbon steel tube designed for heat exchangers, condensers, and boiler systems. Compliant with ASTM A214/ASME SA214 standards, these tubes offer a tensile strength of at least 47 ksi (325 MPa) and yield strength of 26 ksi (180 MPa), making them ideal for high-temperature and pressure applications in power plants, petrochemical processing, and HVAC systems.
ASTM A214 Carbon Steel Pipe are heat treated at a temperature of 1200℉(650℃) or higher and following by cooling in air or in a cooling chamber of a controlled atmosphere furnace.
Manufactured through electric resistance welding, ASTM A214 ERW Boiler Tubes undergo heat treatment at 1650°F (900°C) or higher, followed by air cooling or controlled furnace cooling to ensure weld integrity and eliminate untempered martensite. Available in sizes up to 3 inches (76.2 mm) in outside diameter, with wall thicknesses from 0.8 mm to 12.7 mm, these tubes can be customized for length (3–12 meters) and surface finishes like bright annealed, polished, or coated for enhanced corrosion resistance.
Rigorous testing, including flattening, flange, reverse flattening, hardness (≤72 HRB), and hydrostatic or nondestructive electric tests, ensures compliance with ASTM A214 standards. These tubes are designed for applications requiring efficient heat transfer, such as in boiler flues, superheater flues, and safe ends, with excellent resistance to thermal stress and corrosion in demanding environments.
Compared to seamless tubes like ASTM A179, ASTM A214 ERW Boiler Tubes offer cost-effective solutions with comparable performance for low to medium-pressure systems. Their carbon steel composition ensures durability and weldability, making them suitable for bending and forming in complex piping systems.
ASTM A214 ERW Boiler Tubes address challenges like pipeline wear, thermal stress, and corrosion, providing reliable, high-performance solutions for heat transfer and boiler applications in industrial settings.
Tensile strength of 325 MPa for demanding heat transfer applications.
Coatings and heat treatment enhance durability in corrosive environments.
ERW process with post-weld heat treatment ensures reliable welds.
Up to 3" OD with customizable lengths and finishes.
Affordable solution for low to medium-pressure systems.
Meets ASTM A214 and ASME SA214 standards.
Explore ASTM A214 ERW Boiler Tubes with targeted long-tail keywords for specifications, applications, and materials.
Note: ASTM A214 ERW Boiler Tubes meet international standards, ensuring high performance and reliability. Contact suppliers for detailed specifications.
| Element | Composition (% max) |
|---|---|
| Carbon (C) | 0.18 |
| Manganese (Mn) | 0.27–0.63 |
| Phosphorus (P) | 0.035 |
| Sulfur (S) | 0.035 |
The low carbon content ensures weldability and durability for ASTM A214 ERW Boiler Tubes in heat transfer applications.
| Property | Value |
|---|---|
| Tensile Strength (min, ksi [MPa]) | 47 [325] |
| Yield Strength (min, ksi [MPa]) | 26 [180] |
| Elongation (min, %) | 35 |
| Hardness (max, HRB) | 72 |
These properties ensure ASTM A214 ERW Boiler Tubes deliver robust performance in high-temperature and pressure environments.
| Feature | ASTM A214 | ASTM A179 | ASTM A178 |
|---|---|---|---|
| Manufacturing Process | ERW | Seamless, Cold-Drawn | ERW |
| Diameter Range | Up to 3" (76.2 mm) | 1/8"–3" (3.2–76.2 mm) | 1/2"–5" (12.7–127 mm) |
| Applications | Heat exchangers, condensers, boilers | Heat exchangers, condensers | Boilers, superheaters |
| Tensile Strength (min, MPa) | 325 | 325 | 325 |
| Cost | Cost-Effective | Higher | Moderate |
ASTM A214 ERW Boiler Tubes provide cost-effective solutions for heat transfer applications compared to seamless tubes like ASTM A179 and ASTM A178 pipes. Below is a comparison of key features.
ASTM A214 ERW Boiler Tubes are engineered for efficient heat transfer in heat exchangers, condensers, boiler systems, power plants, petrochemical processing, and HVAC systems, ensuring reliable performance in high-temperature environments.
Durable tubes for efficient heat transfer in industrial heat exchangers.
High-strength tubes for reliable condensing processes.
Robust tubes for boiler flues and superheater applications.
Reliable tubes for high-temperature steam lines in power generation.
Corrosion-resistant tubes for handling corrosive fluids in refineries.
Efficient tubes for heating and cooling applications.
Why Choose ASTM A214 ERW Boiler Tubes? Their high-strength, corrosion-resistant design ensures reliable performance in critical heat transfer and boiler applications.
