Check Valve
Robust Non-return Design For Industrial Pipeline Protection
A check valve is a mechanical device that allows the flow of fluid in one direction while preventing its backflow in the opposite direction.
Robust Non-return Design For Industrial Pipeline Protection
A check valve is a mechanical device that allows the flow of fluid in one direction while preventing its backflow in the opposite direction.
Check valves are one-way valves that allow fluid to flow in a single direction and automatically prevent backflow. They are widely used in pipelines to protect pumps, piping, and other equipment. Backflow preventers apply additional pressure to ensure water flows only one way, providing extra protection for drinking water systems.
A check valve allows fluid to flow in one direction while preventing reverse flow. It is commonly installed in pipelines to protect pumps, valves, and other equipment. Key functions include flow control, backflow prevention, and protection of critical system components.
Both devices prevent backflow but work differently: Check valves use a hinged or spring-loaded disc, flap, or piston that opens with forward flow and closes with reverse flow. Backflow preventers use pressure and multiple fail-safes to ensure water flows in only one direction, providing higher reliability for drinking water systems.
Hinged disc swings open for forward flow and closes to prevent backflow. Minimal turbulence and low pressure drop. Suitable for low-pressure surge systems.
Piston or ball lifts from the seat to allow flow. Suitable for high-pressure and high-velocity systems. Can be installed horizontally or vertically.
Compact and cost-effective. Full-bore design prevents solids buildup. Self-cleaning rotating ball ensures reliability, commonly used in wastewater applications.
Disc rotates to allow flow. Compact design for large-diameter piping. Commonly used where space is limited.
Tilting disc design reduces water hammer and ensures fast closure. Ideal for industrial pipelines with variable flow conditions.
Spring-assisted disc moves along a central stem. Quick-acting closure prevents water hammer, suitable for pumped systems. Disc always present in flow stream; slightly higher headloss than swing type.
Choosing the correct check valve ensures efficient, safe, and reliable operation. Consider the type, size, material, and specifications based on your system's operating conditions.
Simple, cost-effective, and compact design. Ideal for wastewater applications due to smooth bore and self-cleaning rotating ball. Does not have an open/close indicator.
Most common type, inexpensive, full-bore design minimizes headloss. Can include visual or digital open/close indicators. Suitable for low-pressure surge systems.
Spring-assisted disc moves along a central stem. Quick-acting closure prevents water hammer. Disc always present in flow stream, slightly higher headloss than swing check valves. Ideal for pumped systems.
The Check Valve, also known as a non-return valve, is a critical component designed for industrial flow control, ensuring unidirectional flow and preventing backflow in pipelines handling water, oil, gas, and other fluids. Engineered for reliability, this valve operates automatically without external actuation, using a spring-loaded disc or swing mechanism to close against reverse flow, protecting pumps, compressors, and other equipment from damage. Constructed from materials like ASTM A216 WCB carbon steel, ASTM A351 CF8M stainless steel, or ductile iron, with optional coatings such as epoxy or PTFE, it offers exceptional corrosion resistance, making it ideal for backflow prevention valve applications in chemical processing, water treatment, and oil and gas industries.
Available in swing, lift, or dual-plate designs, the check valve comes in sizes from 1/2" to 60" (DN15 to DN1500) and supports pressure ratings up to PN40 (ANSI Class 150-600) and temperatures from -29°C to 200°C, depending on seat materials like EPDM, Viton, or metal-to-metal seals for high-temperature applications. Compliant with API 594 for design, API 598 for testing, and ASME B16.34 for manufacturing, it ensures tight sealing and minimal pressure loss (Cv values up to 12,000). Certifications such as API 6D for pipeline valves and NSF 61 for potable water validate its performance in non-return valve duties across HVAC, power generation, and marine systems.
The valve’s robust construction features a one-piece body and a blowout-proof stem, reducing leak paths and enhancing durability under high-pressure conditions. Its corrosion resistant check valve properties are bolstered by coatings that withstand aggressive media like seawater, acids, and slurries, extending service life up to three times longer than uncoated valves in corrosive environments. The low cracking pressure (as low as 0.1 bar) ensures quick response to flow changes, while the streamlined disc design minimizes turbulence and pressure drop, optimizing efficiency in industrial flow control. Rigorous testing, including hydrostatic, air, and cycle endurance per API 598, confirms tensile strengths above 485 MPa, ensuring reliability under cyclic loading and thermal stress.
Compared to gate or globe valves, the check valve offers a compact, lightweight design—up to 50% lighter—reducing installation costs and space requirements in backflow prevention valve applications. Its self-actuating mechanism eliminates the need for manual or automated controls, lowering operational costs while maintaining performance in high-vibration settings like refineries or offshore platforms. Optional features, such as soft seats for bubble-tight sealing or spring-assisted closure for low-flow systems, enhance versatility for wastewater, fire protection, and petrochemical pipelines. The valve’s ability to handle bidirectional pressure with minimal maintenance makes it a sustainable choice for eco-friendly operations.
Addressing challenges like backflow-induced equipment damage, corrosion, and high maintenance, this non-return valve incorporates durable seals and a robust hinge mechanism to ensure long-term integrity. Its compatibility with ANSI, DIN, and JIS flange standards, along with wafer, lug, or flanged end connections, ensures global applicability. Surface treatments like 3LPE or FBE coatings further enhance durability in corrosion resistant check valve applications. Whether preventing reverse flow in municipal water systems or protecting compressors in gas pipelines, the Check Valve delivers reliable, low-maintenance industrial flow control for diverse global operations.
Engineered for reliable backflow prevention with robust materials and low-maintenance design.
Check valves are essential components that ensure safe and efficient operation of fluid systems by controlling flow direction and preventing backflow.
Permits fluid flow in one direction and automatically closes to prevent backflow in the opposite direction.
Uses hinged or spring-loaded flaps, discs, or pistons that open with forward flow and close with backflow.
Includes swing, lift, ball, and diaphragm check valves, each suited for different applications and conditions.
Widely used in water, wastewater, oil & gas, HVAC, and many other industrial applications.
Helps avoid sudden pressure surges caused when fluid flow is abruptly stopped.
Simple and reliable design ensures long-term efficiency with minimal upkeep.
Check valves are one-way valves that allow fluid to flow in a single direction and automatically prevent backflow. They are widely used in pipelines to protect pumps, piping, and other equipment. Backflow preventers apply additional pressure to ensure water flows only one way, providing extra protection for drinking water systems.
Allows fluid to flow in one direction and automatically prevents backflow.
Protects pumps, piping, and other equipment.
Check Valve: Simple, hinged or spring-loaded disc.
Backflow Preventer: Uses pressure and fail-safes to protect drinking
water.
Hinged disc swings open to allow forward flow and closes to prevent backflow.
Low turbulence and low pressure drop.
Piston or ball lifts from the seat to allow flow.
Suitable for high-pressure and high-velocity systems; can be installed horizontally or
vertically.
Ball Check, Butterfly Check, and Tilting-Disk Check valves.
Each design is optimized for specific applications and conditions.
- Unidirectional flow control
- Low maintenance
- Prevents water hammer
- Wide range of sizes & materials
- Versatile in water, oil, gas, and HVAC systems
| Feature | Check Valve | Backflow Preventer |
|---|---|---|
| Primary Function | Allows flow in one direction; prevents reverse flow automatically | Prevents contamination of drinking water; ensures flow only in one direction using pressure & fail-safes |
| Mechanical Design | Hinged disc, flap, piston, or ball opens with flow and closes with backflow | Multiple valves, check mechanisms, or air gaps to enforce one-way flow |
| Application | Pipelines, pumps, HVAC, water & wastewater, oil & gas | Potable water supply, irrigation, hospitals, schools, commercial buildings |
| Pressure Handling | Medium to high pressure; depends on valve type | High reliability; designed for pressurized systems to prevent contamination |
| Maintenance | Low; simple design, few moving parts | Moderate; more components, periodic inspection recommended |
| Reliability | Good for general use; may fail under extreme conditions | Highly reliable; multiple fail-safes for drinking water protection |
| Organization | Standard | Description |
|---|---|---|
| ANSI | American National Standards Institute | General industrial standards |
| API | American Petroleum Institute | Standards for oil and gas industry |
| ASME | American Society of Mechanical Engineers | Boiler and pressure vessel codes |
| BS | British Standards | UK national standards |
| GB, JB, HG | China Valve Standards | Chinese national and industry standards |
Upstream, midstream, and downstream operations, including drilling, refining, and transportation.
Handling corrosive and hazardous chemicals in various chemical plants.
Steam, water, and fuel systems in thermal, nuclear, and hydroelectric plants.
Municipal water supply, wastewater treatment, and industrial water management.
Heating, ventilation, and air conditioning systems in commercial and industrial buildings.
Sterile and hygienic applications, precise flow control in sensitive industries.
